Lux 1

Coming Summer 2021
$750.00
Assembly Options Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Mechanical Disc
Tire Size
27.5 x 2.35"
Frame material
Aluminum

We designed the Diamondback Lux 1 mountain bike to suit a wide range of rider heights looking to get into mountain biking. The sleek frame provides plenty of standover clearance so you can easily maneuver the bike. With 27.5” wheels for quick handling, the Lux stays calm and collected in nearly every situation — whether that’s climbing a steep trail, winding through twisty singletrack, or letting loose on the downhills. We also equipped the Lux with beefy 2.35” tires, Tektro mechanical disc brakes, and a 3×8 speed Shimano drivetrain with tons of gears. The end result? Traction, control, and speed that will have you planning the next ride as soon as you finish the last one.

  • Frame Lux 27.5 Double Butted 6061-T6 Aluminum Super Low TT for Increased Clearance, w/ Formed Top / Down Tube
  • Fork SR Suntour XCT30 27.5", 80mm Travel, Coil Spring w/ Preload Adjust
  • Headset 1 1/8" Zero Stack
  • Cranks Shimano Tourney TY501, 42/34/24T
  • Bottom Bracket Sealed Cartridge
  • Front Derailleur Shimano Altus M313, Top Swing, Dual Pull, 34.9mm Clamp Diameter
  • Rear Derailleur Shimano Altus M310, 8 Speed
  • Shifter Shimano EF-500 Easyfire, 3x8 Speed
  • Cogset Shimano HG-31, 8 Speed Cassette, 11-32T
  • Chain KMC Z82, 8 Speed
  • Front Hub 32h Alloy w/ CNC Disc Mount; 100mm
  • Rear Hub 32h Alloy w/ CNC Disc Mount, Cassette; 135mm
  • Spokes 14g Stainless Steel
  • Rims 32h Diamondback DP25 Doublewall
  • Tires Vee Tire Crown Gem 27.5x2.35 Tires
  • Brake Levers Shimano EF-500
  • Pedals DB4L Aluminum Platform
  • Handlebar Diamondback, 740mm Wide, 15mm Rise, 31.8 Bar Bore
  • Grips DB D2 Kraton
  • Stem DB 3D Forged, 7° Rise, 31.8 Bar Bore
  • Seat DB Performance MTB Saddle
  • Seatpost Aluminum Micro Adjust, 30.9mm
  • Extras Tool Kit
  • Brakes Tektro Aries Mechanical Disc, w/ 160mm Front and Rear Rotors
  • Product ID 4691

* Specifications are subject to change without notice

Frame Size SM/15 5'3"-5'5" MD/17 5'5"-5'7" LG/19 5'7"-5'10"
Rider Height - - -
Bike Stand Over Height 639.0 mm 647.0 mm 664.0 mm
Bike Seat Tube Length 380.0 mm 430.0 mm 480.0 mm
Bike Top Tube Length 555.0 mm 580.0 mm 595.0 mm
Bike Head Tube Length 95.0 mm 105.0 mm 115.0 mm
Bike Head Angle 68.0 ° 68.0 ° 68.0 °
Bike Seat Angle 73.2 ° 73.3 ° 73.4 °
Bike Wheel Base 1070.0 mm 1096.0 mm 1112.0 mm
Bike Chain Stay Length 430.0 mm 430.0 mm 430.0 mm
Bike Fork Offset 46.0 mm 46.0 mm 46.0 mm
Bike Bb Height 304.0 mm 304.0 mm 304.0 mm
Bike Bb Drop 44.0 mm 44.0 mm 44.0 mm
Bike Stem Length 75.0 mm 90.0 mm 90.0 mm
Bike Handlebar Width 740.0 mm 740.0 mm 740.0 mm
Bike Crank Length 170.0 mm 170.0 mm 175.0 mm
Bike Seat Post Length 350.0 mm 350.0 mm 350.0 mm
Bike Stack 526.0 mm 546.0 mm 555.0 mm
Bike Reach 393.0 mm 416.0 mm 427.0 mm
Bike Fork Travel 80.0 mm 80.0 mm 80.0 mm
