Hatch 2

$650.00
Assembly Options Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Mechanical Disc
Tire Size
XS, S: 27.5x2.25"; M, L, XL: 29x2.25"
Frame material
Aluminum

At home on dirt, gravel, and pavement, the Hatch 2 keeps the adventure going when it’s time to explore the path less travelled. To give you the ideal balance of stability and easy handling, the Hatch features Progressive Wheel Sizing, using the wheel size that best matches the rider size. A 100mm travel fork and grippy 2.25-inch wide knobby tires help you easily roll over bumps and potholes with confidence. With 21 gear combinations at your fingertips, you’ll always find a comfortable pedaling pace, and Tektro mechanical disc brakes provide reliable stopping power. Own your adventure without breaking the bank on the Hatch.

  • Bike Frame Custom Formed AL-6061 Heat Treated Aluminum with Progressive wheel Sizing (27.5" - XS,S) (29" - M,L,XL)
  • Bike Fork SR Suntour XCE-28 100mm of Travel with Pre-Load Adjuster, IS Disc mounts
  • Bike Headset 1-1/8 Semi Integrated,Cartridge Bearing
  • Bike Cranks Shimano Tourney TY301, 42/34/24t
  • Bike Bottom Bracket BSA, Sealed Cartridge Bearing
  • Bike Front Derailleur Shimano Tourney TY500, Dual Pull
  • Bike Rear Derailleur Shimano Tourney TY300
  • Bike Shifter Shimano EF500 3x7 Speed EZ-Fire Shifter
  • Bike Cogset Shimano MFTZ500 14-28 Tooth Freewheel
  • Bike Chain KMX Z-7
  • Bike Front Hub Formula DC-19 Aluminum 6 bolt Disc, Quick Release
  • Bike Rear Hub Formula DC-31, Aluminum 6 bolt Disc, Quick Release
  • Bike Spokes Steel J-Bend
  • Bike Rims Aluminum MTB DDM-2 Double Wall, 32 hole
  • Bike Tires Vee Tire Co. Rubber Rail Escape, 27.5x2.25 or 29x2.25"
  • Bike Brake Levers Shimano EF500 with 2-finger, Reach Adjustable Levers
  • Bike Pedals Wellgo Plastic Body Platform
  • Bike Handlebar Aluminum 31.8mm Bar, 25mm Rise
  • Bike Grips MTB Grip
  • Bike Stem Aluminum MTB 31.8 Bar Bore Stem
  • Bike Seat MTB Saddle
  • Bike Seatpost Aluminum 27.2 Post with 15mm Offset
  • Bike Extras Rack, Fender and Bottle Mounts
  • Bike Brakes Tektro M280 IS Post Mount, Mechanical Disc w 160mm Rotors F/R
  • Product ID 4731
Frame Size XS/14 (27.5) 5'1" - 5'4" SM/15 (27.5) 5'4" - 5'7" MD/17 (29) 5'7" - 5'10" LG/19 (29) 5'10" - 6'1" XL/21 (29) 6'1" - 6'4"
Rider Height - - - - -
Bike Stand Over Height 720.0 mm 750.0 mm 778.0 mm 809.0 mm 844.0 mm
Bike Seat Tube Length 360.0 mm 400.0 mm 440.0 mm 480.0 mm 530.0 mm
Bike Top Tube Length 540.0 mm 565.0 mm 590.0 mm 615.0 mm 640.0 mm
Bike Head Tube Length 100.0 mm 110.0 mm 95.0 mm 110.0 mm 125.0 mm
Bike Head Angle 68.0 ° 68.0 ° 69.5 ° 69.5 ° 69.5 °
Bike Seat Angle 73.5 ° 73.5 ° 73.0 ° 73.0 ° 73.0 °
Bike Wheel Base 1050.0 mm 1075.0 mm 1097.0 mm 1123.0 mm 1149.0 mm
Bike Chain Stay Length 425.0 mm 425.0 mm 444.0 mm 444.0 mm 444.0 mm
Bike Fork Offset 42.0 mm 42.0 mm 46.0 mm 46.0 mm 46.0 mm
Bike Bb Height 305.0 mm 305.0 mm 310.0 mm 310.0 mm 310.0 mm
Bike Bb Drop 50.0 mm 50.0 mm 60.0 mm 60.0 mm 60.0 mm
Bike Stem Length 75.0 mm 90.0 mm 90.0 mm 105.0 mm 105.0 mm
Bike Handlebar Width 720.0 mm 720.0 mm 720.0 mm 720.0 mm 720.0 mm
Bike Crank Length 170.0 mm 170.0 mm 175.0 mm 175.0 mm 175.0 mm
Bike Seat Post Length 350.0 mm 350.0 mm 350.0 mm 350.0 mm 350.0 mm
Bike Stack 588.0 mm 597.0 mm 617.0 mm 631.0 mm 645.0 mm
Bike Reach 366.0 mm 388.0 mm 401.0 mm 422.0 mm 443.0 mm
