Haanjo 7C Carbon
Part road bike, part cyclocross bike, part mountain bike, the Diamondback Haanjo 7C is 100 percent awesome … and ready for any adventure. The full carbon frame and fork are light, tough, and designed around our Endurance Geometry, which puts you in the perfect position to comfortably hammer out long miles on pavement, gravel, and dirt. Praxis cranks are paired with Shimano GRX drivetrain components for a gear range that keeps you pedalling smoothly both on- and off-road. The HED Tomcat tubeless ready wheels play nice with wide tires, making this bike truly versatile. Don’t want the ride to end just because the sun went to bed? We also equipped the Haanjo 7C with rack mounts, so you can extend your stay in the wilds.
- Frame DB Carbon Alternative Road Frame, Endurance Geometry, Relaxed Headtube Angle, Disc Specific, w/ 142x12 Thru-axle, Replaceable Hanger
- Fork DB Gravel Performance, Full Monocoque Carbon, Carbon 12mm Thru Axle Drop Outs, Flat Mount Disc ready, w/Tapered Steerer Tube
- Headset FSA No.42, Sealed Cartridge
- Cranks Praxis Cadet Direct Mount, 48/32T
- Bottom Bracket Praxis M30 Sealed
- Front Derailleur Shimano GRX810, 31.8mm Band Clamp
- Rear Derailleur Shimano GRX810, Shadow Plus, 11 Speed
- Shifter Shimano GRX600 Dual Control 2x11 Speed
- Cogset Shimano CS-HG70011 Cassette, 11 Speed, 11-34T
- Chain KMC X11EL, 11 Speed
- Front Hub 24h Aluminum Sealed Cartridge, Center Lock, 12mm Thru-axle
- Rear Hub 24h Aluminum Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette
- Spokes 2.0/1.8/2.0 Butted Stainless Steel
- Rims HED Tomcat Disc 24h, 21mm Internal Width, Tubeless Ready
- Tires WTB Riddler, Dual DNA Compound, Lightweight Casing Tubeless, 700x37c
- Brake Levers Shimano GRX600
- Handlebar HED, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore
- Grips Diamondback Endurance Gel Tape
- Stem HED, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore
- Seat WTB Silverado Race
- Seatpost HED Pro Tour Carbon, 27.2mm
- Extras Tool Kit, Chainstay Protector, Carbon Paste, Tubeless Ready - Tubeless Valves included, Sealant required to complete (not included).
- Brakes Shimano BR-RX400 Flat Mount Hydraulic Disc, w/160mm F / 160mm R, RT70 Rotors
- Product ID 4484
* Specifications are subject to change without notice
| Frame Size | 50cm 5'5"-5'8" | 53cm 5'8"-5'11" | 56cm 5'11"-6'2" | 59cm 6'2"-6'6" |
|---|---|---|---|---|
| Rider Height | - | - | - | - |
| Bike Stand Over Height | 788.0 mm | 808.0 mm | 834.0 mm | 858.0 mm |
| Bike Seat Tube Length | 500.0 mm | 530.0 mm | 560.0 mm | 590.0 mm |
| Bike Top Tube Length | 525.0 mm | 540.0 mm | 560.0 mm | 580.0 mm |
| Bike Head Tube Length | 130.0 mm | 155.0 mm | 175.0 mm | 200.0 mm |
| Bike Head Angle | 69.0 ° | 70.0 ° | 71.0 ° | 72.0 ° |
| Bike Seat Angle | 74.5 ° | 73.5 ° | 72.5 ° | 72.0 ° |
| Bike Wheel Base | 1028.0 mm | 1025.0 mm | 1025.0 mm | 1028.0 mm |
| Bike Chain Stay Length | 430.0 mm | 430.0 mm | 430.0 mm | 430.0 mm |
| Bike Fork Offset | 45.0 mm | 45.0 mm | 45.0 mm | 45.0 mm |
| Bike Bb Height | 280.0 mm | 280.0 mm | 280.0 mm | 280.0 mm |
| Bike Bb Drop | 70.0 mm | 70.0 mm | 70.0 mm | 70.0 mm |
| Bike Stem Length | 80.0 mm | 90.0 mm | 100.0 mm | 110.0 mm |
| Bike Handlebar Width | 440.0 mm | 440.0 mm | 460.0 mm | 460.0 mm |
| Bike Crank Length | 170.0 mm | 172.5 mm | 172.5 mm | 175.0 mm |
| Bike Seat Post Length | 350.0 mm | 350.0 mm | 350.0 mm | 350.0 mm |
| Bike Stack | 543.0 mm | 570.0 mm | 593.0 mm | 622.0 mm |
| Bike Reach | 374.0 mm | 371.0 mm | 373.0 mm | 378.0 mm |
| Bike Fork Length | 395.0 mm | 395.0 mm | 395.0 mm | 395.0 mm |
