Haanjo 5

Coming Summer 2021
Rating:
100 % of 100
$2,050.00
Assembly Options Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Hydraulic disc
Tire Size
700x37c
Frame material
Aluminum

You’re lost. And that’s a good thing because the Diamondback Haanjo 5 is a gravel bike designed to help you get off the beaten track. That’s why we built it around our trustworthy 6061 alloy frame and carbon fork with thru axles front and rear. The path off road is rarely flat and smooth. Accordingly, we outfitted this beast with plenty of gears as well as HED Tomcat wheels shod with grippy WTB Riddler 700×37c tires. Finally, we’ve updated this ride to include Shimano GRX600 2×11 shifters, giving you more control when you need it. Looking for your next great adventure? When the road turns bad, this bike gets really good.

  • Frame DB Alternative Road, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Aluminum Formed Top Tube, Tapered Headtube, Flat Mount Disc , 142x12mm Thru-axle w/Replaceable Hanger
  • Fork DB Gravel Performance, Full Monocoque Carbon, Carbon 12mm Thru Axle Drop Outs, Flat Mount Disc ready, w/Tapered Steerer Tube
  • Headset FSA No.42, Sealed Cartridge
  • Cranks Shimano GRX600, 46/30T
  • Bottom Bracket Shimano Outboard Bearing
  • Front Derailleur Shimano GRX810, 31.8mm Band Clamp
  • Rear Derailleur Shimano GRX810, Shadow Plus, 11 Speed
  • Shifter Shimano GRX600, Dual Control 2x11 Speed
  • Cogset Shimano HG70011 Cassette, 11 Speed, 11-34T
  • Chain KMC X11EL, 11 Speed
  • Front Hub 28h Aluminum Sealed Cartridge, Center Lock, 12mm Thru-axle
  • Rear Hub 28h Aluminum Sealed Cartridge, Center Lock, 142x12mm Thru-axle, Cassette
  • Spokes 2.0/1.8/2.0 Butted Stainless Steel
  • Rims HED Tomcat Disc, 28h, 21mm Internal Width, Tubeless Ready
  • Tires WTB Riddler, Dual DNA Compound, 700x37c
  • Brake Levers Shimano GRX600
  • Pedals DB Resin Gravel Platform
  • Handlebar HED Eroica, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore
  • Grips Diamondback Endurance Gel Tape
  • Stem HED Eroica, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore
  • Seat WTB Silverado Race
  • Seatpost HED Eroica, 6061 Aluminum 27.2mm
  • Extras Tool Kit, Tubeless Valves, Chainstay Protector, Carbon Paste
  • Brakes Shimano BR-RX400 Flat Mount Hydraulic Disc, w/160mm Front / 160mm Rear, RT70 Rotors
  • Product ID 4478

* Specifications are subject to change without notice

Frame Size XS/47 5'1"-5'4" SM/50 5'4"-5'8" MD/53 5'7"-5'10" LG/56 5'10"-6'1" XL/60 6'1"-6'4"
Rider Height - - - - -
Bike Stand Over Height 701.0 mm 727.0 mm 776.0 mm 811.0 mm 845.0 mm
Bike Seat Tube Length 395.0 mm 450.0 mm 505.0 mm 535.0 mm 565.0 mm
Bike Top Tube Length 525.0 mm 525.0 mm 545.0 mm 560.0 mm 580.0 mm
Bike Head Tube Length 105.0 mm 120.0 mm 155.0 mm 175.0 mm 200.0 mm
Bike Head Angle 70.0 ° 70.0 ° 72.0 ° 72.0 ° 72.0 °
Bike Seat Angle 75.0 ° 75.0 ° 73.5 ° 73.5 ° 73.5 °
Bike Wheel Base 1033.0 mm 1039.0 mm 1041.0 mm 1041.0 mm 1062.0 mm
Bike Chain Stay Length 440.0 mm 440.0 mm 440.0 mm 440.0 mm 440.0 mm
Bike Fork Offset 50.0 mm 50.0 mm 50.0 mm 50.0 mm 50.0 mm
Bike Bb Height 280.0 mm 280.0 mm 280.0 mm 280.0 mm 280.0 mm
Bike Bb Drop 70.0 mm 70.0 mm 70.0 mm 70.0 mm 70.0 mm
Bike Stem Length 0.0 mm 80.0 mm 90.0 mm 100.0 mm 110.0 mm
Bike Handlebar Width 0.0 mm 440.0 mm 440.0 mm 460.0 mm 460.0 mm
Bike Crank Length 0.0 mm 170.0 mm 172.5 mm 172.5 mm 175.0 mm
Bike Seat Post Length 0.0 mm 350.0 mm 350.0 mm 350.0 mm 350.0 mm
Bike Stack 536.0 mm 550.0 mm 583.0 mm 610.0 mm 633.0 mm
Bike Reach 380.0 mm 377.0 mm 367.0 mm 379.0 mm 392.0 mm
Bike Fork Length 404.0 mm 404.0 mm 404.0 mm 404.0 mm 404.0 mm
