Atroz 2
$1,375.00
Assembly Options
Professionally assembled by your local dealer, or DIY the assembly - its up to you!
Financing Available
Buy Now, Pay Later with Klarna. We’ve partnered with Klarna to offer flexible payment options to pay over time.
30 Day Returns
Our love your ride guarantee – if you’re not 100% happy with your bike, we’re not happy either. Click here for more details
Frame Warranty
Covered for at least 5 years! Check out the details to see if your bike qualifies for longer.
Brakes
Hydraulic disc
Tire Size
27.5 x 2.35"
Frame material
6061 T-6 Aluminum
We love hardtails, but there’s no denying the benefits of full-suspension mountain bikes — the added comfort and control. Unfortunately, dualies often add another thing: more dollar signs to the price tag. That’s not the case here. The Atroz utilizes sealed cartridge bearings in an understated single-pivot design to deliver smooth, durable performance. The Atroz 2 ups the ante with Shimano hydraulic disc brakes, Suntour air-sprung rear suspension and an easy-to-operate single-ring drivetrain — features you usually find on bikes with a whole lot more dollar signs on their price tags.
- Frame Atroz 6061 T-6 Aluminum 27.5 Trail w/ 4" travel, Optimized Single Pivot, Tapered Steerer, Machine Formed Top Tube, Butted / Formed Down Tube, Sealed Cartridge Bearing Pivot, Seat Tube Routed for Internal Dropper Post, Aggressive Geometry, Replaceable Hanger
- Rear Shock SR Suntour Raidon-R, Air Shock w/ Rebound Adjust, 184x44mm
- Fork SR Suntour XCM 120mm Travel, 30mm Stanchions, w/ Preload Adjust
- Headset FSA NO.57, Sealed Cartridge for Tapered Headtube
- Cranks Aluminum Arm w/ 30T Steel "Narrow Wide" Single Ring
- Bottom Bracket Sealed Cartridge
- Front Derailleur Full ISCG-05 Chain Guide w/ Roller
- Rear Derailleur Shimano Acera M3000 Shadow, 9 Speed
- Shifter Shimano Acera M3000, 9 Speed
- Cogset Shimano HG200, 9 Speed, 11-36T
- Chain KMC Z9, 9 Speed
- Front Hub Formula Hubs, 32h Aluminum w/ CNC Disc Mount
- Rear Hub Formula Hubs, 32h Aluminum Cassette w/ CNC Disc mount
- Spokes 14g Stainless Steel
- Rims 32H, DDM-5, 27.5 Double Wall, Not Taped
- Tires VEE Rubber, Flow Snap, 27.5x2.35, Non Tubless Tire
- Brake Levers Shimano MT200 Hydraulic
- Pedals DB4L Aluminum Platform
- Handlebar Diamondback, 750mm Wide, 15mm Rise, 31.8 Bar Bore
- Grips New DB "Flanged" 135mm Silcone
- Stem Diamondback "Shortie", 45mm Reach, 31.8 Bar Bore
- Seat DB Sync'r Saddle
- Seatpost Aluminum Micro Adjust, 30.9mm
- Extras Tool Kit, Not Tubeless Compatible
- Brakes Shimano MT200 Hydraulic Disc, w/ 180mm Front and Rear Rotors
- Product ID 4684
* Specifications are subject to change without notice
| Frame Size | SM 5'4" - 5'7" | MD 5'7" - 5'10" | LG 5'10" - 6'1" |
|---|---|---|---|
| Rider Height | - | - | - |
| Bike Stand Over Height | 752.0 mm | 768.0 mm | 801.0 mm |
| Bike Seat Tube Length | 380.0 mm | 430.0 mm | 480.0 mm |
| Bike Top Tube Length | 550.0 mm | 585.0 mm | 615.0 mm |
| Bike Head Tube Length | 110.0 mm | 110.0 mm | 120.0 mm |
| Bike Head Angle | 66.5 ° | 66.5 ° | 66.5 ° |
| Bike Seat Angle | 72.5 ° | 72.5 ° | 72.5 ° |
| Bike Wheel Base | 1095.0 mm | 1130.0 mm | 1161.0 mm |
| Bike Chain Stay Length | 435.0 mm | 435.0 mm | 435.0 mm |
| Bike Fork Offset | 44.0 mm | 44.0 mm | 44.0 mm |
| Bike Bb Height | 330.0 mm | 330.0 mm | 330.0 mm |
| Bike Bb Drop | 10.0 mm | 10.0 mm | 10.0 mm |
| Bike Stem Length | 50.0 mm | 50.0 mm | 50.0 mm |
| Bike Handlebar Width | 750.0 mm | 750.0 mm | 750.0 mm |
| Bike Crank Length | 170.0 mm | 175.0 mm | 175.0 mm |
| Bike Seat Post Length | 300.0 mm | 300.0 mm | 300.0 mm |
| Bike Stack | 559.0 mm | 559.0 mm | 568.0 mm |
| Bike Reach | 373.0 mm | 408.0 mm | 435.0 mm |
| Bike Fork Travel | 120.0 mm | 120.0 mm | 120.0 mm |
